The UltraTech 2223 is an extra-rugged, low-profile secondary containment platform engineered for the secure staging of up to four 55-gallon drums, heavy equipment, or facility machinery. Molded from high-density linear low-density polyethylene with UV inhibitors, this heavy-duty unit delivers an exceptional static load capacity of 10,000 pounds per square foot to withstand rigorous industrial handling and maintenance operations. The platform features a 35-gallon structural sump and a low 4.25-inch deck height to reduce manual loading height restrictions, while integrated ports allow mechanical connection to other spill deck modules using bulkhead fittings to expand containment arrays and fulfill compliance mandates.
Key Features
-
Industrial Load Threshold: Engineered with an extra-rugged structural core capable of sustaining static uniform distributed loads up to 10,000 lbs. per square foot, supporting heavy machinery, batteries, and filled chemical drums.
-
Low-Profile Height Reduction: Features a low 4.25-inch structural profile that minimizes safety overhead concerns during drum handling sequences and provides a shallow gradient for compatible equipment loading ramps.
-
Modular Sump Expansion Ports: Pre-drilled for optional bulkhead fittings, enabling the mechanical linkage of multiple 2-drum and 4-drum modules to create a shared fluid containment system customized to facility floor dimensions.
-
Corrosion-Resistant Composition: Fabricated from linear low-density polyethylene with UV inhibitors to offer comprehensive durability against severe physical impact, outdoor exposure, and aggressive chemical leaks.
-
Regulatory Compliance Integration: Provides a 35-gallon standalone sump volume that, when interconnected via bulkhead connectors to adjacent deck sumps, allows industrial facilities to satisfy strict EPA 40 CFR 264.175 and SPCC regulations.
- Product Title
- UltraTech 2223 Spill Deck Plus P4
- Manufacturer
- UltraTech International
- Part Number
- 2223
- UPC Code
- 808416022230
- Drum Capacity
- 4 Drums (55-Gallon)
- Material Composition
- Linear Low-Density Polyethylene (LLDPE) with UV Inhibitors
- Color Configuration
- Yellow Sump / Black Grates
- Dimensions (L x W x H)
- 54.5" x 54.5" x 4.25" (1,384 mm x 1,384 mm x 108 mm)
- Product Weight
- 104.0 lbs (47.2 kg)
- Containment Sump Capacity
- 35.0 Gallons (132.5 Liters)
- Static Load Capacity UDL
- 10,000 lbs per sq. ft. (4,536 kg)
- Grating Dimensions
- 52.0" x 26.0" x 4.0" (Two grates included)
- Drain Included
- No
- Forklift Access
- No Pockets (Static setup only)
- Compatible Loading Ramp
- UltraTech 2353 Steel Ramp (Sold Separately)
- Regulatory Alignment
- EPA 40 CFR 264.175 and SPCC Frameworks (when linked to additional modules)
