The UltraTech 1175 Spill Deck P6 is a heavy-duty, one-piece secondary containment platform engineered to safely store up to six 55-gallon drums. This unibody system features a single, seamless molded sump that completely eliminates the need for connecting hardware or bulkhead fittings while maintaining a low profile. At just 5.25 inches in height, the deck layout maximizes facility safety by lowering the working clearance required to safely load, unload, and dispense fluids from industrial drums.
Key Features
-
Seamless Sump Design: Molded as a one-piece unit with zero assembly seams or joints, eliminating internal leak paths across all six drum storage areas.
-
Low-Profile Interface: At 5.25 inches tall, this platform reduces employee lifting strain and addresses height liabilities common to high-clearance spill pallets.
-
High Distributed Load Rating: Features a uniformly distributed load (UDL) capacity of 9,000 lbs, allowing reliable and balanced placement of fully laden steel or poly drums.
-
Robust Chemical Resistance: Constructed from linear low-density polyethylene (LLDPE) to protect workspaces against corrosive acids, caustics, and aggressive shop chemicals.
-
Regulatory Compliance: Provides an integrated 66-gallon sump capacity that satisfies SPCC regulations and EPA Container Storage Regulation 40 CFR 264.175 requirements.
| Specification | Data |
|---|---|
| Part Number | 1175 |
| Drum Capacity | 6-Drum |
| Structure Type | One-Piece Molded Sump |
| Dimensions | 74.25" x 50" x 5.25" (1886 x 1270 x 133 mm) |
| Grating Surface Area | 72" x 48" (1829 x 1219 mm) |
| Load Capacity (UDL) | 9,000 lbs (4,082 kg) |
| Sump Capacity | 66 Gallons (250 Liters) |
| Material | Linear Low-Density Polyethylene with UV Inhibitors |
| Weight | 90 lbs (41 kg) |
