The UltraTech 0802 is an industrial secondary containment system engineered for the safe storage and handling of up to four 55-gallon drums. This specialized unit combines an 85-gallon baseline containment sump with a removable drum deck featuring contoured rings that secure containers against shifting. Outfitted with an integrated threaded sidewall drain plug, this heavy-duty asset permits rapid fluid extraction while permanently isolating hazardous liquid leaks and preventing environmental ground contamination.
Key Features
-
Contoured Drum Alignment Deck: Designed with a removable, dark gray deck featuring molded positioning rings that lower the container center of gravity and keep drum arrays securely balanced.
-
85-Gallon Sump with Drain: Outfitted with an uncompromised, leak-proof baseline reservoir that exceeds federal compliance capacities and features a built-in sidewall plug for tool-free fluid drainage.
-
Heavy-Duty Load Rating: Engineered from premium, high-density polymer materials to sustain a uniform static load capacity of up to 6,500 pounds indefinitely.
-
Safe Double-Stacking Profile: Built with structural internal reinforcements that allow operators to safely double-stack drums vertically, maximizing warehouse floor space layouts.
-
Industrial Polyethylene Composition: Molded from a high-strength polymer matrix that delivers exceptional resistance to degradation from fuels, oils, solvents, acids, and aggressive chemicals.
| Specification | Value |
|---|---|
| Product Title | UltraTech 0802 Spill King with Drum Pallet, With Drain |
| Manufacturer | UltraTech International |
| Part Number | 0802 (Model 802) |
| UPC Code | 808416008029 |
| Drum Capacity | 4 Drums (55-Gallon) |
| Material Composition | High-Density Polyethylene (HDPE) |
| Color Configuration | Brick Red Sump / Dark Gray Deck |
| Dimensions (L x W x H) | 51" x 51" x 17.5" (1,295 mm x 1,295 mm x 445 mm) |
| Containment Sump Capacity | 85.0 Gallons (321.8 Liters) |
| Static Load Capacity UDL | 6,500 lbs (2,948 kg) |
| Integrated Drain | Yes (3/4" NPT Threaded Polyethylene Plug) |
| Regulatory Standards | EPA Container Storage Regulation 40 CFR 264.175, SPCC, and UFC Spill Containment |
