UltraTech 9850 Grate Guard, 24" x 24", Sediment, High Flow, With Overflows
- Sediment-Only High-Flow Model – Configured as a “Sediment Only Model, High Flow w/ Overflows” to allow increased stormwater throughput while retaining sediment, silt, and debris.
- 24" x 24" x 4" Catch Basin Coverage – Sized for 24" x 24" flat grate catch basins (609.6 x 609.6 mm) with a 4" (101.6 mm) depth for sediment storage volume at the inlet.
- High-Flow Woven Polypropylene Fabric – Manufactured from high-flow woven polypropylene geotextile with tested tensile strength, puncture resistance, and flow characteristics for stormwater filtration.
- Hook-and-Loop Closure Attachment – Slides onto the storm drain grate and secures with heavy-duty hook-and-loop fasteners so the unit stays in place but can be removed and reinstalled without tools.
- Street-Level Sediment Cleanout – Keeps sediment, dirt, and debris at street level where they can be removed with a broom or flat shovel, reducing the need to lift the grate and helping support stormwater BMP programs.
- Model Number
- 9850
- Product Type
- Ultra-Grate Guard – Sediment Only, High Flow with Overflows
- Dimensions
- 24" L x 24" W x 4" H (609.6 x 609.6 x 101.6 mm)
- Grate/Drain Compatibility
- Flat grate catch basins – 24" x 24" opening (nominal)
- Weight
- 2 lbs (0.9 kg)
- Material
- High-Flow Woven Polypropylene Geotextile
- Flow Classification
- High Flow with Overflows
- Sediment/Oil Control
- Sediment Only Model – captures sediment, silt, and debris; allows runoff to flow through
- Overflow Features
- Integrated overflow provisions for bypass flow during high-intensity rainfall events
- Attachment Method
- Slides onto grate with heavy-duty hook-and-loop fasteners
- Color
- Hi-Vis Green / High-Visibility Lime
- Country of Origin
- Guatemala (subject to change)
- Brand
- UltraTech International
- Compliance
- Helps support compliance with NPDES 40 CFR 122.26 and TMDL stormwater requirements when used as part of a BMP program
- Liftgate service required if the site has no loading dock.
- Driver will not move freight inside the building.
- Inspect and note damage on the delivery receipt before signing.
- Freight claims filed by us on your behalf within 48 hours.
- Residential and limited-access sites carry a carrier accessorial; we quote it before dispatch.
