EKKO EK30D Pneumatic Diesel Forklift 6,000 lbs cap, 185" Lift Height
The EKKO EK30D is a diesel-powered 4-wheel counterbalanced forklift designed for material handling, warehousing, distribution, and outdoor operations where diesel fuel is preferred or required over LPG. Powered by a Tier 4 EPA-compliant Mitsubishi 4EG diesel engine rated at 49 HP, it delivers a 6,000 lb. load capacity with a maximum lift height of 185 inches at a 24-inch load center. The unit features a multifunctional suspended seat for vibration reduction, an adjustable steering column, an impedance-composed muffler for reduced sound output, and solid pneumatic tires for all-surface stability. Standard equipment includes a Cascade side shift and Shimadzu 4-way hydraulic valve pre-plumbed, making this model well suited for distribution centers, loading docks, manufacturing facilities, and outdoor yard operations.
- 6,000 lb. Lift Capacity at 24 in. Load Center - Rated for loads up to 6,000 lbs at a 24 in. load center with a maximum lift height of 185 in. and a free lifting height of 37.9 in.
- Tier 4 EPA-Compliant Mitsubishi Diesel Engine - Powered by a Mitsubishi 4EG diesel engine producing 49 HP at 2,250 RPM and meeting Tier 4 EPA emissions standards for indoor and outdoor operation
- Heavy-Duty Solid Pneumatic Tires - 28x9-15-12PR front and 6.50-10-10PR rear solid pneumatic tires deliver consistent traction on concrete, asphalt, and uneven outdoor surfaces without flat risk
- Cascade Side Shift and Shimadzu Hydraulics Standard - Factory-installed Cascade side shift and Shimadzu 4-way valve come pre-plumbed for precise load positioning and responsive mast control straight from delivery
- Operator Comfort and Noise Reduction Package - Multifunctional suspended seat distributes operator weight and reduces vibration, while an impedance-composed muffler and adjustable steering column lower fatigue during continuous operation
- Model Number
- EK30D
- Product Type
- 4-Wheel Diesel Counterbalanced Forklift
- Load Capacity
- 6,000 lbs
- Load Center
- 24 in.
- Lift Height
- 185 in.
- Free Lifting Height
- 37.9 in.
- Overall Height with Forks Lifted
- 234 in.
- Mast Overall Height (Lowered)
- 86.2 in.
- Overall Length (with Forks)
- 151 in.
- Overall Length (without Forks)
- 106 in.
- Overall Width
- 48.2 in.
- Wheelbase
- 66.9 in.
- Ground Clearance (at Mast)
- 4.7 in.
- Service Weight
- 10,108 lbs
- Fork Size
- 42 in. x 4.9 in. x 1.7 in.
- Engine
- Mitsubishi 4EG Diesel
- Engine Power
- 49 HP at 2,250 RPM
- Fuel Type
- Diesel
- Max Travel Speed (Loaded / Unloaded)
- 11 mph / 12.1 mph
- Tire Type
- Solid Pneumatic
- Tire Size
- 28x9-15-12PR (Front) / 6.50-10-10PR (Rear)
- Service Brake
- Hydraulic Floor Pedal
- Hydraulic Valve
- Shimadzu 4-Way (Pre-Plumbed)
- Side Shift
- Cascade (Standard)
- Battery
- 12V / 60Ah
- Compliance / Certifications
- Tier 4 EPA
- Warranty
- 3-Year Structural / 2-Year Engine / 1-Year Parts
- Brand
- EKKO Lifts
