EKKO EK07S Counterbalanced Walkie Stacker | 118" Lift Height | 1550 lb Capacity
The EKKO EK07S is a fully powered counterbalanced walkie stacker designed for loading docks, stock rooms, manufacturing floors, and warehouse environments requiring a lightweight, compact no-outrigger stacking unit with a 1,550 lb. capacity and 118-inch lift height. At 84.7 inches overall length and 34.5 inches overall width with a 51-inch turning radius, this is the most compact counterbalanced stacker in the EKKO lineup, suited for tight aisle applications and space-constrained facilities where larger counterbalanced units cannot operate. The counterbalanced frame eliminates straddle legs entirely, allowing the unit to pick and place pallets from low-clearance racking and floor-level positions, powered by a 24V AC 0.75 kW drive motor, 24V 1.5 kW lift motor, and Curtis controller with an on-board 24V / 20A charger included. Battery, on-board charger, and a 3-year limited warranty are included standard.
- 1,550 lb. Capacity with 118 in. Maximum Lift Height - Rated for 1,550 lbs at a 20 in. load center with a maximum lift height of 118 in. and a lowered mast height of 81.1 in. for low-clearance aisle and door entry
- Counterbalanced Design — No Straddle Legs Required - The counterbalanced frame eliminates outrigger arms and straddle legs, allowing the unit to place and retrieve loads from ground-level racking with restricted clearance where standard straddle stackers cannot operate
- Compact 51 in. Turning Radius with 84.7 in. Overall Length - At 34.5 in. overall width, 84.7 in. overall length, and a 51 in. turning radius, the EK07S is the most maneuverable counterbalanced stacker in the EKKO product line and suited for confined storage environments
- 24V AC 0.75 kW Drive and 1.5 kW Lift Motor with Curtis Controller - Equipped with a 24V AC 0.75 kW drive motor and 24V 1.5 kW lift motor controlled by a Curtis controller for fully powered drive and lift operation with polyurethane wheels for smooth indoor floor performance
- 24V / 120Ah Battery and On-Board 24V / 20A Charger Included - Ships with a 24V / 120Ah battery and an on-board 24V / 20A charger at no additional cost, with a service weight of 2,090 lbs and a robotically welded steel frame backed by a 3-year limited warranty
- Model Number
- EK07S
- Product Type
- Fully Powered Counterbalanced Walkie Stacker
- Load Capacity
- 1,550 lbs
- Load Center
- 20 in.
- Lift Height
- 118 in.
- Mast Overall Height (Lowered)
- 81.1 in.
- Overall Length
- 84.7 in.
- Overall Width
- 34.5 in.
- Turning Radius
- 51 in.
- Service Weight
- 2,090 lbs
- Fork Size (Thick / Width / Length)
- 1.4 in. x 2.9 in. x 42 in.
- Fork Adjust Width
- 8.3 in. – 25.2 in.
- Power Type
- Electric
- Battery
- 24V / 120Ah (Included)
- On-Board Charger
- 24V / 20A (Included)
- Drive Motor
- 24V / 0.75 kW AC
- Lift Motor
- 24V / 1.5 kW
- Controller
- Curtis
- Tire Type
- Polyurethane
- Construction
- Steel with Robotic Welding
- Warranty
- 3-Year Limited
- Brand
- EKKO Lifts
- Liftgate service required if the site has no loading dock.
- Driver will not move freight inside the building.
- Inspect and note damage on the delivery receipt before signing.
- Freight claims filed by us on your behalf within 48 hours.
- Residential and limited-access sites carry a carrier accessorial; we quote it before dispatch.
